ZOOM H4E ESSENTIAL HANDY RECORDER

Zoom H4essential Portable Recorder

The Zoom H4essential is a powerful and flexible 4-track portable recorder built for musicians, content creators, and field recordists who need professional-grade audio capture with minimal setup. Featuring 32-bit float recording with dual A/D converters, it delivers completely clip-free recordings without the need to adjust gain.

Its 130 dB SPL XY stereo microphones handle everything from quiet acoustic sources to loud live environments, while two XLR/TRS combo inputs with locking connectors and an additional 3.5mm mic/line input provide extensive connectivity for microphones, instruments, and external audio sources.

A built-in mixer allows real-time level balancing across all tracks, and the colour LCD screen makes navigation and monitoring straightforward. The H4essential also functions as a USB audio interface, enabling seamless integration with computers and mobile devices while recording directly to SD card at the same time.

With support for up to 1TB SD cards, Bluetooth control (via optional adapter), and flexible powering options, it’s a highly capable recording solution for both studio and on-location use.

Key Features

• 4-track recorder with 32-bit float and dual A/D converters
• No gain setting required – clip-free recording
• 130 dB SPL XY stereo microphones
• Records up to 96kHz sample rate
• 2 × XLR/TRS combo inputs with locking connectors
• 3.5mm mic/line input (supports lavaliers and line sources)
• Built-in mixer for per-track level control
• Colour LCD display
• USB audio interface (PC, Mac, iOS, Android)
• Simultaneous interface use and SD recording
• Bluetooth compatibility via optional BTA-1 adapter
• Built-in speaker for quick playback
• Up to 1TB SD card support
• Up to 10 hours battery life (AA or USB-C power)

Specifications

Inputs & Outputs

• Built-in mic: 90º XY stereo, unidirectional
• Max SPL: 130 dB
• XLR/TRS inputs: 2 (locking combo)
• Mic/Line input: 3.5mm stereo (plug-in power supported)
• Phantom power: +48V (≤10 mA total)
• Headphone output: Stereo mini jack
• Output level: 20 mW + 20 mW (32Ω load)
• Built-in speaker: 250 mW

Recording

• Tracks: 4 simultaneous recording/playback
• Format: WAV (BWF, iXML supported)
• Sample rates: 44.1 / 48 / 96 kHz
• Bit depth: 32-bit float
• Storage: microSDHC (4–32GB), microSDXC (64GB–1TB)

Display & Connectivity

• Display: 2.0" colour LCD (360 × 240)
• USB: Type-C (USB 2.0 High Speed)
• Audio interface:
  • 4-in / 2-out (multi)
  • 2-in / 2-out (stereo)

Power

• 2 × AA batteries (Alkaline, NiMH, Lithium)
• USB-C bus power supported

Approx. battery life (2-track, XY mics):

• Alkaline: ~9 hours
• NiMH: ~9 hours
• Lithium: ~19 hours

(Shorter runtime when using multiple inputs or phantom power)

Physical

• Dimensions: 66.9 × 156.1 × 38.0 mm
• Weight: 243 g (with batteries)

Summary

A versatile, professional-grade portable recorder that combines multi-track capability, flexible inputs, and fail-safe 32-bit float recording, making it ideal for everything from music production to field recording and content creation.
